Informações Tećnicas

• Maximum Rating: 994 bkW
• Minimum Rating: 298 bkW
• Aspiration: Turbocharged-aftercooled

Mais informações

Power Rating

• Minimum Rating: 298 bkW / 400 BHP
• Maximum Rating: 994 bkW / 1333 BHP

Engine Specifications

• Aspiration: Turbocharged-aftercooled
• Rotation: Counterclockwise from flywheel end
• Bore: 145 mm / 5.71 in
• Configuration: Vee 12, 4-stroke-cycle diesel
• Stroke: 162 mm / 6.38 in
• Displacement: 32.1 l / 1959 in³
• Emissions: U.S. EPA Tier 4 Final certified, IMO III emissions certified (SCR required)
• Oil Change Interval: 750 hrs - deep pan
• Rated Engine Speed: 1800 rpm
• Governor: Electronic (A5 ECM)
• Refill Capacity: Lube Oil System w/ oil filter change: 146 L (38.5 gal) - deep pan
• Cooling: Heat exchanger or keel cooled
• Flywheel Housing: SAE No. 0 with SAE No. 18 flywheel (136 teeth)

Dimensions & Weights

• Maximum Width: 1455 mm / 57.3 in
• Maximum Height: 1613 mm / 63.5 in
• Maximum Engine Dry Weight: 3248 kg / 7160 lb
• Minimum Engine Dry Weight: 3152 kg / 6950 lb
• Minimum Length: 2130 mm / 83.9 in
• Maximum Length: 2280 mm / 89.8 in
• Minimum Width: 1451 mm / 57.1 in
• Minimum Height: 1507 mm / 59.3 in

Clean Emissions Module (CEM) - Dimensions

• 6 Brick Z-Flow - Weight: 565 kg / 1246 lb
• 6 Brick Z-Flow - Width: 1106 mm / 43.5 in
• Dosing Cabinet - Length: 949 mm / 37.4 in
• Dosing Cabinet - Width: 477 mm / 18.8 in
• 6 Brick U-Flow - Height: 597 mm / 23.5 in
• 6 Brick Z-Flow - Height: 597 mm / 23.5 in
• 6 Brick U-Flow - Weight: 560 kg / 1235 lb
• Dosing Cabinet - Weight: 95 kg / 209 lb
• 6 Brick U-Flow - Width: 1445 mm / 56.9 in
• 6 Brick Z-Flow - Length: 3751 mm / 147.7 in
• Dosing Cabinet - Height: 579 mm / 22.8 in
• 6 Brick U-Flow - Length: 2159 mm / 85 in
