MP324 Pulverizer Jaw – MULTI-PROCESSADORES

  • ColeçãoColeçãoMULTI-PROCESSADORES
carousel
carousel
carousel
carousel
carousel
carousel
carousel
carousel
carousel
carousel
carousel
carousel

Descrição

Cat® Multi-Processors accept multiple interchangeable jaws for a wide range of demolition tasks. Faster cycle times get your jobs done quicker. Greater power means taking on bigger jobs. Quick jaw change gives you the right tool for the task at hand, without slowing you down. All built on a durable, easy to maintain platform.

Mais informações

Performance

  • Cycle Time – Open: 1.8 s / 1.8 s
  • Cycle Time – Close: 1.2 s / 1.2 s
  • Crushing Force – Tooth Tip: 1104 kN / 124 Sh Ton
  • Crushing Force – Cutter Tip: 1664 kN / 187 Sh Ton
  • Crushing Force – Primary Cutter: 3727 kN / 419 Sh Ton

Hydraulic Requirements

  • Jaw Circuit – Max. Oil Pressure: 350 bar / 5076 psi
  • Jaw Circuit – Max. Oil Flow: 225 l/min / 59 gal/min
  • Rotation Circuit – Max. Oil Pressure: 140 bar / 2031 psi
  • Rotation Circuit – Max. Oil Flow: 40 l/min / 11 gal/min

Dimensions – Jaw

  • Jaw Depth: 764 mm / 30 in
  • Cutter Length: 200 mm / 8 in
  • Jaw Opening – Maximum: 965 mm / 38 in
  • Jaw Width – Fixed: 519 mm / 20 in
  • Jaw Width – Moveable: 337 mm / 13 in

Dimensions – Housing Jaw +

  • Length: 2183 mm / 86 in
  • Height: 1466 mm / 58 in
  • Width: 793 mm / 31 in

Weight

  • Weight – Housing, Jaw and Bracket: 2826 kg / 6230 lb
  • Weight – Jaw Only: 1200 kg / 2646 lb

Recommended Carrier Weight

  • Excavator Minimum: 24 tons
  • Excavator Maximum: 35 tons
