Cat® Multi-Processors accept multiple interchangeable jaws for a wide range of demolition tasks. Faster cycle times get your jobs done quicker. Greater power means taking on bigger jobs. Quick jaw change gives you the right tool for the task at hand, without slowing you down. All built on a durable, easy to maintain platform.

Mais informações

Performance

• Cycle Time – Open: 1.6 s / 1.6 s
• Cycle Time – Close: 1 s / 1 s
• Crushing Force – Tooth Tip: 781 kN / 88 Sh Ton
• Crushing Force – Cutter Tip: 1131 kN / 127 Sh Ton
• Crushing Force – Primary Cutter: 2570 kN / 289 Sh Ton

Hydraulic Requirements

• Jaw Circuit – Max. Oil Pressure: 350 bar / 5076 psi
• Jaw Circuit – Max. Oil Flow: 150 l/min / 40 gal/min
• Rotation Circuit – Max. Oil Pressure: 140 bar / 2031 psi
• Rotation Circuit – Max. Oil Flow: 40 l/min / 11 gal/min

Dimensions – Jaw

• Jaw Depth: 666 mm / 26 in
• Cutter Length: 200 mm / 8 in
• Jaw Opening – Maximum: 824 mm / 32 in
• Jaw Width – Fixed: 480 mm / 19 in
• Jaw Width – Moveable: 300 mm / 12 in

Dimensions – Housing Jaw +

• Length: 2006 mm / 79 in
• Height: 1307 mm / 51 in
• Width: 793 mm / 31 in

Weight

• Weight – Housing, Jaw and Bracket: 2077 kg / 4579 lb
• Weight – Jaw Only: 865 kg / 1907 lb

Recommended Carrier Weight

• Excavator Minimum: 18 tons
• Excavator Maximum: 25 tons
