C7.1 (50 Hz) - GRUPOS GERADORES

  • ColeçãoColeçãoGRUPOS GERADORES
carousel
carousel
carousel
carousel
carousel
carousel

Descrição

Caterpillar is leading the power generation marketplace with Power Solutions engineered to deliver unmatched flexibility, expandability, reliability, and cost-effectiveness.

Informações Tećnicas

  • Minimum Rating: 135 kVA
  • Maximum Rating: 220 kVA
  • Emissions/Fuel Strategy: Non Regulated, EU Stage IIIA

Mais informações

Generator Set Specifications

  • Minimum Rating: 135 kVA
  • Maximum Rating: 220 kVA
  • Voltage: 110 to 480 Volts
  • Frequency: 50 Hz
  • Speed: 1500 rpm
  • Emissions/Fuel Strategy: Non Regulated, EU Stage IIIA
  • Length - Maximum: 2500 mm / 98.4 in
  • Width - Maximum: 1320 mm / 52 in
  • Height - Maximum: 1626 mm / 64 in
  • Duty Cycle: Standby, Prime

Generator Set Configurations

  • Emissions/Fuel Strategy: Non Regulated, EU Stage IIIA

Engine Specifications

  • Engine Model: Cat® C7.1
  • Displacement: 7 l / 427.8 in³
  • Fuel System: Direct Injection
  • Aspiration: Turbocharged, Air to Air Aftercooled
  • Governor Type: Mechanical
  • Bore: 105 mm / 4.1 in
  • Compression Ratio: 16.0:1, 18.2:1
  • Stroke: 135 mm / 5.3 in

Generator Set Dimensions

  • Length - Maximum: 2500 mm / 98.4 in
  • Width - Maximum: 1320 mm / 52 in
  • Height - Maximum: 1626 mm / 64 in

Dimensions

  • Length - Maximum: 2500 mm / 98.4 in
  • Width - Maximum: 1320 mm / 52 in
  • Height - Maximum: 1626 mm / 64 in
