Caterpillar is leading the power generation marketplace with Power Solutions engineered to deliver unmatched flexibility, expandability, reliability, and cost-effectiveness.

Informações Tećnicas

• Minimum Rating: 13.0 kVA
• Maximum Rating: 22.0 kVA
• Emissions/Fuel Strategy: EU Stage IIIA

Mais informações

Generator Set Specifications

• Minimum Rating: 13.0 kVA
• Maximum Rating: 22.0 kVA
• Voltage: 110 to 415 Volts
• Frequency: 50 Hz
• Speed: 1500 rpm
• Emissions/Fuel Strategy: R96/EUIIIa Equivalent
• Length – Maximum: 1500 mm / 59.1 in
• Width – Maximum: 620 mm / 24.4 in
• Height – Maximum: 1115 mm / 43.9 in
• Duty Cycle: Standby, Prime

Generator Set Configurations

• Emissions/Fuel Strategy: EU Stage IIIA

Engine Specifications

• Engine Model: Cat® C2.2, In-line 4, 4-cycle diesel
• Displacement: 2.2 l / 135.2 in³
• Fuel System: Indirect Injection
• Compression Ratio: 22.5:1
• Governor Type: Mechanical
• Bore: 84 mm / 3.3 in
• Stroke: 100 mm / 3.9 in
• Aspiration: Naturally Aspirated

Generator Set Dimensions

• Length – Maximum: 1500 mm / 59.1 in
• Width – Maximum: 620 mm / 24.4 in
• Height – Maximum: 1115 mm / 43.9 in

Dimensions

• Length – Maximum: 1500 mm / 59.1 in
• Width – Maximum: 620 mm / 24.4 in
• Height – Maximum: 1115 mm / 43.9 in
