Descrição

Caterpillar is leading the power generation marketplace with Power Solutions engineered to deliver unmatched flexibility, expandability, reliability, and cost-effectiveness.

Informações Tećnicas

  • Minimum Rating: 550 kVA
  • Maximum Rating: 715 kVA
  • Emissions/Fuel Strategy: Low Fuel Consumption, U.S. EPA Certified for Stationary Emergency Use Only (Tier 2 Nonroad Equivalent Emission Standards), China Nonroad III Emission Standards

Mais informações

Generator Set Specifications

  • Minimum Rating: 550 kVA
  • Maximum Rating: 715 kVA
  • Voltage: 380 to 415 Volts
  • Frequency: 50 Hz
  • Speed: 1500 rpm
  • Emissions/Fuel Strategy: Low Fuel, China Nonroad III Emis Stds
  • Bore: 145 mm / 5.71 in
  • Stroke:
  • Length – Maximum: 4135 mm / 162.4 in
  • Width – Maximum: 1989 mm / 78.3 in
  • Height – Maximum: 1906 mm / 75 in
  • Duty Cycle: Standby, Prime

Generator Set Configurations

  • Emissions/Fuel Strategy: Low Fuel Consumption, U.S. EPA Certified for Stationary Emergency Use Only (Tier 2 Nonroad Equivalent Emission Standards), China Nonroad III Emission Standards

Engine Specifications

  • Stroke: 183 mm / 7.2 in
  • Engine Model: C18 ATAAC, I-6, 4-Stroke Water-Cooled Diesel
  • Displacement: 18.13 l / 1106.36 in³
  • Fuel System: Electronic unit injection
  • Aspiration: Air to Air Aftercooled
  • Governor Type: Ademâ„¢A4
  • Compression Ratio: 14.5:1
  • Bore: 145 mm / 5.71 in
  • Stroke – HD:

Generator Set Dimensions

  • Length – Maximum: 4135 mm / 162.4 in
  • Width – Maximum: 1989 mm / 78.3 in
  • Height – Maximum: 1906 mm / 75 in

Dimensions

  • Length – Maximum: 4135 mm / 162.4 in
  • Width – Maximum: 1989 mm / 78.3 in
  • Height – Maximum: 1906 mm / 75 in
