Caterpillar is leading the power generation marketplace with Power Solutions engineered to deliver unmatched flexibility, expandability, reliability, and cost-effectiveness.

Informações Tećnicas

• Minimum Rating: 12.0 ekW
• Maximum Rating: 13.2 ekW
• Emissions/Fuel Strategy: R96/EUIIIa Equivalent

Mais informações

Generator Set Specifications

• Minimum Rating: 12.0 ekW
• Maximum Rating: 13.2 ekW
• Emissions/Fuel Strategy: R96/EUIIIa Equivalent
• Voltage: 110 to 415 Volts
• Frequency: 60 Hz
• Speed: 1800 rpm
• Duty Cycle: Standby, Prime

Engine Specifications

• Engine Model: Cat® C1.5
• Bore: 84 mm / 3.3 in
• Stroke: 90 mm / 3.5 in
• Displacement: 1.5 l / 91.3 in³
• Compression Ratio: 22.5:1
• Aspiration: Naturally Aspirated
• Fuel System: Indirect Injection
• Governor Type: Mechanical

Generator Set Dimensions

• Length - Maximum: 1400 mm / 55.1 in
• Width - Maximum: 90 mm / 24.4 in
• Height - Maximum: 1054 mm / 41.5 in
