Hydraulic and Manual Cat® Angle Brooms for Skid Steer Loaders, Multi Terrain Loaders, Compact Track Loaders, Backhoe Loaders, Compact Wheel Loaders and Small Wheel Loaders are ideal for clearing parking lots, industrial plants, mill yards, airport runways, streets, driveways and lanes.

Informações Tećnicas

• Overall Width: 2637 mm
• Sweeping Width: 2119 mm
• Brush Diameter: 815 mm

Mais informações

Geral

• Optimal Hydraulic Flow: 42-86 L/min (11-23 gpm)
• Interface Type: Skid Steer Coupler
• Overall Width: 2637 mm / 104 in
• Sweeping Width: 2119 mm / 83 in
• Brush Diameter: 815 mm / 32 in
• Height: 918 mm / 36 in
• Length: 1741 mm / 69 in
• Weight: 433 kg / 955 lb
• Optimal Hydraulic Pressure: 145-235 bar (2100-3400 psi)
• Motor Displacement: 405 cm³/rev / 25 in³/rev
• Brush Speed at Maximum Flow: 199 rpm
• Sweeping Width - Angled (± 30 Degrees): 1849 mm / 73 in
• Required Hydraulics: Standard Flow
• Overall Width - Angled (± 30 Degrees): 2508 mm / 99 in
• Drive Method: Direct Drive
• Optional Hood Extension: 18 kg / 40 lb
