Caterpillar is leading the power generation marketplace with Power Solutions engineered to deliver unmatched flexibility, expandability,reliability, and cost-effectiveness.

Informações Tećnicas

• Minimum Rating: 2363 kVA
• Maximum Rating: 3575 kVA
• Emissions/Fuel Strategy: Low Fuel Consumption

Mais informações

Generator Set Specifications

• Minimum Rating: 2363 kVA
• Maximum Rating: 3575 kVA
• Frequency: 50 Hz
• Speed: 750 & 1000 rpm
• Duty Cycle: Standby, Prime, Continuous
• Emissions/Fuel Strategy: Low Fuel Consumption
• Length – Maximum: 10261.7 mm / 404 in
• Width – Maximum: 2530.3 mm / 99.62 in
• Height – Maximum: 3977.7 mm / 156.6 in
• Dry Weight – Genset (maximum): 41390 kg / 91050 lb

Engine Specifications

• Engine Model: 3608 I-8,4-Stroke Water-Cooled Diesel
• Displacement: 148 l / 9064 in³
• Total Displacement: 148 l / 9064 in³
• Fuel System: Direct unit injection
• Aspiration: TA
• Governor Type: Generator Set Monitoring System (GMS)
• Compression Ratio: 13:01
• Bore: 280 mm / 11 in
• Stroke: 300 mm / 11.8 in

Dimensions

• Length – Maximum: 10261.7 mm / 404 in
• Width – Maximum: 2530.3 mm / 99.62 in
• Height – Maximum: 3977.7 mm / 156.6 in
• Dry Weight – Genset (maximum): 41390 kg / 91050 lb

Generator Set Dimensions

• Length – Maximum: 10261.7 mm / 404 in
• Width – Maximum: 2530.3 mm / 99.62 in
• Height – Maximum: 3977.7 mm / 156.6 in
• Dry Weight – Genset (maximum): 41390 kg / 91050 lb
