3512B (50 Hz) – GRUPOS GERADORES

  • ColeçãoColeçãoGRUPOS GERADORES
carousel
carousel
carousel
carousel
carousel
carousel
carousel
carousel

Descrição

Caterpillar is leading the power generation market with Power Solutions engineered to deliver unmatched flexibility, expandability, reliability, and cost-effectiveness.

Informações Tećnicas

  • Minimum Rating: 1320 kVA
  • Maximum Rating: 1875 kVA
  • Emissions/Fuel Strategy: Low Fuel Consumption, Low Emissions

Mais informações

Generator Set Specifications

  • Minimum Rating: 1320 kVA
  • Maximum Rating: 1875 kVA
  • Voltage: 380 to 415 Volts
  • Frequency: 50 Hz
  • Speed: 1500 rpm
  • Emissions/Fuel Strategy: Low Fuel, Low Emissions
  • Length – Maximum: 5469 mm / 215.3 in
  • Width – Maximum: 2286 mm / 90 in
  • Height – Maximum: 2367 mm / 93.2 in
  • Duty Cycle: Standby, Mission Critical, Prime

Generator Set Configurations

  • Emissions/Fuel Strategy: Low Fuel Consumption, Low Emissions

Engine Specifications

  • Engine Model: 3512B TA, V-12, 4-Stroke Water-Cooled Diesel
  • Displacement – HD: 58.56 l / 3573.55 in³
  • Displacement – Std: 51.8 l / 3161.03 in³
  • Fuel System: Electronic Unit Injection
  • Aspiration: TA
  • Governor Type: Adem™3
  • Compression Ratio: 14.0:1 Std 15.5:1 HD
  • Bore: 170 mm / 6.69 in
  • Stroke – Standard: 190 mm / 7.48 in
  • Stroke – HD: 215 mm / 8.46 in
  • Stroke: 190 mm / 7.48 in
  • Displacement: 51.8 l / 3161.03 in

Generator Set Dimensions

  • Length – Maximum: 5469 mm / 215.3 in
  • Width – Maximum: 2286 mm / 90 in
  • Height – Maximum: 2367 mm / 93.2 in
  • Length – Minimum: 5249 mm / 206.6 in
  • Width – Minimum: 1975 mm / 77.8 in
  • Dry Weight – Genset (minimum): 11350 kg / 25010 lb
  • Dry Weight – Genset (maximum): 12180 kg / 26840 lb

Dimensions

  • Length – Maximum: 5469 mm / 215.3 in
  • Width – Maximum: 2286 mm / 90 in
  • Height – Maximum: 2367 mm / 93.2 in
  • Length – Minimum: 5249 mm / 206.6 in
  • Width – Minimum: 1975 mm / 77.8 in
  • Dry Weight – Genset (minimum): 11350 kg / 25010 lb
  • Dry Weight – Genset (maximum): 12180 kg / 26840 lb
