Cat® General Purpose Performance Series Buckets provide good all-around performance for stockpiling, re-handling, excavating and bank loading. As the name suggests, these buckets work well in loading from stockpiles as well as bank loading. Performance Series Buckets utilize a system-based approach to balance bucket shape against the machine's linkage, weight, lift and tilt capacities. The result is a bucket optimized for performance and productivity, and intended for use in production applications. The benefits of this design bring higher fill factors and material retention.

Informações Tećnicas

• Rated Capacity: 1.8 m³
• Width: 2401 mm
• Weight: 608.7 kg

Mais informações

Geral

• Width: 2401 mm / 94.5 in
• Weight: 608.7 kg / 1342 lb
• Height: 1080 mm / 42.5 in
• Cutting Edge Thickness: 19 mm / 0.7 in
• Length: 1099 mm / 43.3 in
• Rated Capacity: 1.8 m³ / 2.2 yd³
• Base Edge Thickness: 19.05 mm / 0.8 in
• Capacity: 1.6 m³ / 2.1 yd³
• Interface Type: Pin On

Base Edge Thickness

• Base Edge Thickness: 19.05 mm / 0.8 in
